Premium CNC routed moisture-resistant HDMR wall paneling, acoustic fluted claddings, and 3D geometric textures finished in PU lacquer and natural wood veneers.
At Shree Ram & Company (Vijeta Stone), our architectural millwork division crafts precision 3D wall paneling, parametric fluting, acoustic baffle ceilings, and decorative door cladding using high-density moisture-resistant (HDMR) engineered boards. Cut on high-precision 5-axis CNC routers and finished with multi-coat PU primers and lacquers, our panels bring refined warmth to luxury interiors.
Certified Action TESA and Greenpanel HDMR boards with >850 kg/m³ density and low water swelling for humid air-conditioned spaces.
Routing continuous flutes, organic wave textures, and parametric geometric profiles with razor-sharp, fuzz-free relief edges.
Sanded to 400-grit smoothness and sealed with moisture-barrier primers, ready for bespoke polyurethane (PU) high-gloss or matte lacquer.
Explore our featured design options below. Click any card to select for inquiry or contact our team for custom site dimensions.
Compare high-density HDMR against standard MDF and commercial plywood for interior architectural 3D wall paneling.
| Material Grade | Ideal Application | Moisture Resistance & Density (kg/m³) | Maintenance Level | Longevity |
|---|---|---|---|---|
| Action TESA / Greenpanel HDMR | 3D Fluted Wall Panels, Pooja Room Backdrops, Feature Walls | Supreme (>850 kg/m³ Density, High Moisture Resistance) | Easy Wipe Down | 20-25 Years |
| Exterior Grade MDF Board | Covered Balcony Ceilings, Dry Interior Room Dividers | High Moisture Resistance (750-800 kg/m³ Density) | Low Maintenance | 15-20 Years |
| Calibrated Birch Plywood | Load-Bearing Wall Units, Concealed French Cleat Backings | High Structural Screw-Holding Strength (700 kg/m³) | Zero Maintenance | 25+ Years |
| Commercial Plywood (MR Grade) | General Carpentry Sub-Frames, Dry False Walls | Moderate Moisture Resistance (Prone to Core Voids) | Standard Upkeep | 12-15 Years |
| Standard Interior MDF (Market Alternative) | Budget Flat Furniture | Poor (<650 kg/m³, Swells Rapidly with Atmospheric Humidity) | Prone to Warping | 5-8 Years |
HDMR stands for High Density Moisture Resistant board. Unlike standard MDF (which has a density around 650–700 kg/m³ and swells when exposed to humidity), HDMR is engineered with a density exceeding 850–900 kg/m³ using specialized synthetic resin binders. This higher fiber density gives HDMR superior screw-holding strength, excellent moisture resistance in air-conditioned environments, and clean, fuzz-free edges during detailed CNC routing that achieve a flawless automotive-grade PU paint finish.
HDMR wall panels are mounted using an interlocking French cleat or aluminum Z-clip sub-frame system. A calibrated plywood or wooden framework (12mm–18mm) is first anchored to the brick or concrete wall using nylon expansion fasteners, creating an air gap that prevents moisture transfer from the masonry. The pre-finished CNC HDMR panels, fitted with matching reverse cleats on their back, lock securely into the sub-frame without any visible screw holes or nails on the decorative front face.
The ideal finish for CNC carved HDMR is multi-coat Polyurethane (PU) paint applied in a controlled dust-free spray booth. The process involves two coats of high-build polyester/PU primer to seal the routed fibers, thorough sanding to 400-grit smoothness, followed by two coats of premium Italian PU topcoat (available in deep matte, satin 20% sheen, or 100% high-gloss buffed finish). PU coatings provide a waterproof, scratch-resistant, and non-yellowing surface that retains its luster for decades.
The cost of custom CNC 3D HDMR wall paneling typically ranges between Rs 280 to Rs 850 per square foot in India. Standard 2D fluted or reeded patterns in 12mm–18mm HDMR board (unpainted or primer-coated) range from Rs 280 to Rs 450 per sq ft. Complex 3D organic wave panels or geometric parametric designs with professional spray-booth PU duco finish range from Rs 550 to Rs 950+ per sq ft, depending on panel thickness and finish specification.
Have a custom dimension, design drawing, or specific stone requirement? Share your project details with our team and get a quick quote within 2 hours.
